The Squirrel Cage Type Graphite Heat Exchanger features a unique squirrel cage design. Made of durable graphite, it offers excellent heat transfer performance, ensuring efficient fluid heating or cooling with reliable operation and long service life.
Sự chi trả:
TT L/C PayPal Westunion MoneygramNguồn gốc sản phẩm:
China， Anhui provinceCổng vận chuyển:
shanghaiThời gian dẫn đầu：
1 monthMOQ:
1Bưu kiện:
wooden caseMàu sắc:
customizedVật liệu:
graphiteLàm việc tạm thời:
-20~130°CÁp lực làm việc:
≤0.3MPa
Product review
The structure of the rat cage type graphite heater consists of various components, including upper and lower covers, upper and lower tube sheets, graphite tubes, baffle plates, and so on. It is typically installed within reaction tanks and storage tanks.The upper tube sheet is firmly affixed to the inner wall of the reactor using a PTFE plate or graphite block. This is done to prevent any shaking or impact with the container.A corrosive or non-corrosive carrier, such as brine or saturated water vapor, circulates within the tubes, with only slight scaling occurring. The exterior of the tubes is in contact with the corrosive mother liquor, and this design allows for easy cleaning.The tubes can be chosen from specifications such as Φ32/25 and Φ50/50. An internal baffle plate is employed to enhance the heat transfer efficiency.The arrangement of the tubes can be classified into one row, two rows, or three rows. Specific specifications can be customized and designed according to the requirements of the users.
Product advantages
In the production of omethoate with dimethyl adipate and the production of methamidophos during the dichloride process, the mouse cage type graphite heat exchanger has replaced the traditional lead coil. This substitution has brought about a revolutionary change in the heat exchange mode of the reaction kettle. It features high heat transfer efficiency and strong corrosion resistance. A large-area heat exchanger can be designed, which shortens the production cycle and reduces energy consumption. Moreover, its service life is greatly prolonged, reaching up to four years or more under normal use, 4 - 5 times that of the lead coil. It is also convenient for maintenance and installation, bringing considerable economic benefits.
Spherical block hole type graphite heat exchanger, a highly durable and efficient heat transfer apparatus commonly employed in various industrial sectors such as chemical, petrochemical, and pharmaceutical industries for precise temperature control and effective heat exchange.
Chi tiết
The shell-and-tube silicon carbide heat exchanger is composed of silicon carbide tubes sealed with tube sheets to form a tube bundle placed inside a cylindrical shell. Ends are equipped with end caps. One fluid flows inside the tubes and the other outside. It's suitable for highly corrosive chemicals, used for cooling, heating, condensation, etc.
Chi tiết
Rectangular Hole Type Graphite Heat Exchanger: A heat transfer device with a rectangular hole pattern in graphite. It offers high thermal conductivity, excellent chemical resistance, and efficient fluid flow for reliable heat exchange in various industrial applications.
Chi tiết
A floating head shell-and-tube graphite heat exchanger is a highly efficient and reliable heat transfer device. It consists of a shell, tubes, a floating head, and other components.
Chi tiết
The tubular graphite heat exchanger is a type of heat transfer equipment fabricated from graphite. It exhibits excellent corrosion resistance and is extensively utilized in industries such as chemical and petrochemical for highly efficient heat exchange processes.
Chi tiết
Bộ trao đổi nhiệt dạng tấm kim loại truyền nhiệt giữa các chất lỏng bằng các tấm kim loại dạng sóng để trao đổi nhiệt hiệu quả.
Chi tiết
Spherical block hole type graphite heat exchanger, a highly durable and efficient heat transfer apparatus commonly employed in various industrial sectors such as chemical, petrochemical, and pharmaceutical industries for precise temperature control and effective heat exchange.
Chi tiết
A Graphite Sulfuric Acid Dilution Cooler is a specialized device designed for the safe dilution of sulfuric acid and the subsequent cooling of the resultant mixture. This ensures that the chemical processing is carried out in an efficient and controlled manner.
Chi tiết
